50mesh Hastelloy X Wire Mesh

Specification:

1. Wire Dia: 0.075mm

2. Mesh Count: 50mesh/inch
3. Aperture: 0.433mm
4. Open Area: 73%

5. Material: hastelloy X wire

6. Weight: 0.15kgs/m2

7. Weave type: plain weave

8. Packing: waterproof paper with plastic cloth,then into plywooden box.

Hastelloy Wire has  resistant to hydrochloric acid at all concentrations and temperatures including the boiling points, and also hydrogen chloride gas.

9.products pctures: 50mesh Hastelloy X Wire Mesh50mesh Hastelloy X Wire Mesh50mesh Hastelloy X Wire Mesh10. Roll size :

1.02m wide x 30.5m length

1.22m wide x 30.5m length

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

10mesh Hastelloy C276 Wire Cloth

Hastelloy C Grade Wire Cloth (UNS:N10276)

1. Mesh Count: 10mesh/inch

2. Wire Diameter: 0.60mm
3. Width of Opening: 1.94mm
4. Open Area: 58%
5. Weave: plain weave

6. Weight: 2.03kgs/m2

7. Packing: waterproof paper with plastic cloth,then wooden case.

Alloy C-276 is an improved version of alloy C in that it has vastly improved fabricability and resists the formation of grain-boundary carbide precipitates during welding.

Hastelloy C276 Chemical Composition %

C Mn Fe V Ni Si S W P Co Mo Cr
Max Max Min/Max Max Max Max Max Min/Max Max Max Min/Max Min/Max
0.02 1.00 4.00-7.00 0.35 Rem 0.08 0.03 3.00-4.50 0.03 2.50 15.0 – 17.0 14.5 – 16.5

10mesh Hastelloy C276 Wire Cloth10mesh Hastelloy C276 Wire Cloth

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

50mesh Hastelloy Wire Mesh

Hastelloy C Grade Wire Cloth (UNS:N10276)

1. Mesh Count: 50mesh/inch
2. Wire Diameter: 0.15mm
3. Width of Opening: 0.358mm
4. Open Area:49.6%
5. Weave: plain weave

6. Weight: 0.63kgs/m2

7. Packing: waterproof paper with plastic cloth,then wooden case.

Alloy C-276 is an improved version of alloy C in that it has vastly improved fabricability and resists the formation of grain-boundary carbide precipitates during welding.

Hastelloy C276 Chemical Composition %

C Mn Fe V Ni Si S W P Co Mo Cr
Max Max Min/Max Max Max Max Max Min/Max Max Max Min/Max Min/Max
0.02 1.00 4.00-7.00 0.35 Rem 0.08 0.03 3.00-4.50 0.03 2.50 15.0 – 17.0 14.5 – 16.5

50mesh Hastelloy Wire Mesh

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

150mesh Hastelloy Wire Mesh

Hastelloy B Grade Wire Cloth (UNS:N10001)

 1. Mesh Count: 150mesh/inch
2. Wire Diameter: 0.05mm
3. Width of Opening: 0.119mm
4. Open Area: 49.5%
5. Weight: 0.211kgs/m2

6. Width of roll: 3′,3.2′,4′,5′ and 6′

7. Length of roll: 100ft and 200ft

8. Packing: waterproof paper with plastic cloth,then wooden case.

Hastelloy wire cloth is the most corrosion-resistant modern metal materials, it is mainly corrosion-resistant to wet chlorine.

Hastelloy B Chemical Composition %

C Mn Fe V Ni Si S Cr P Co Mo
Max Max Max Max Max Max Max Max Max Max Min/Max
0.12 1.00 6.00 0.60 Rem 1.00 0.03 1.00 1.00 2.50 26.0 – 33.0

150mesh Hastelloy Wire Mesh

Hastelloy C Grade Wire Cloth (UNS:N10276)

Mesh/Inch: 6mesh to 200mesh

Wire Dia:0.05mm to 1.20mm

Alloy C-276 is an improved version of alloy C in that it has vastly improved fabricability and resists the formation of grain-boundary carbide precipitates during welding.

Hastelloy C276 Chemical Composition %

C Mn Fe V Ni Si S W P Co Mo Cr
Max Max Min/Max Max Max Max Max Min/Max Max Max Min/Max Min/Max
0.02 1.00 4.00-7.00 0.35 Rem 0.08 0.03 3.00-4.50 0.03 2.50 15.0 – 17.0 14.5 – 16.5

Hastelloy X Grade Wire Cloth (UNS: N06002)

Mesh/Inch:

20meshx20mesh

50meshx50mesh

Hastelloy X Grade Wire Cloth (UNS: N0833Mesh/Inch:

10meshx10mesh

18meshx18mesh

20meshx20mesh

50meshx50mesh

60meshx60mesh

Wire Dia: 0.19mm to 0.65mm

Hastelloy X Chemical Composition %

C Mn Fe Sn Ni Si S Cr P Cu
Max Max Max Max Max Max Max Max Max Max
0.08 2.00 Rem 0.025 34.0- 37.0 0.75 – 1.50 0.03 17.0- 20.0 0.03 1.00

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

Hastelloy X Wire Cloth

Hastelloy X Grade Wire Cloth (UNS: N06002)

Mesh/Inch:

20meshx20mesh

50meshx50meshHastelloy X Wire ClothHastelloy X Grade Wire Cloth (UNS: N08330)

Mesh/Inch:

10meshx10mesh

18meshx18mesh

20meshx20mesh

50meshx50mesh

60meshx60mesh

Wire Dia: 0.19mm to 0.65mm

Hastelloy X Chemical Composition %

C Mn Fe Sn Ni Si S Cr P Cu
Max Max Max Max Max Max Max Max Max Max
0.08 2.00 Rem 0.025 34.0- 37.0 0.75 – 1.50 0.03 17.0- 20.0 0.03 1.00

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com



12mesh Hastelloy C276 Wire Cloth

Hastelloy C Grade Wire Cloth (UNS:N10276)

1. Mesh Count: 12mesh/inch

2. Wire Diameter: 0.40mm
3. Width of Opening: 1.717mm
4. Open Area: 66%
5. Weave: plain weave

6. Weight: 1.08kgs/m2

7. Packing: waterproof paper with plastic cloth,then wooden case.

Alloy C-276 is an improved version of alloy C in that it has vastly improved fabricability and resists the formation of grain-boundary carbide precipitates during welding.

Hastelloy C276 Chemical Composition %

C Mn Fe V Ni Si S W P Co Mo Cr
Max Max Min/Max Max Max Max Max Min/Max Max Max Min/Max Min/Max
0.02 1.00 4.00-7.00 0.35 Rem 0.08 0.03 3.00-4.50 0.03 2.50 15.0 – 17.0 14.5 – 16.5

12mesh Hastelloy C276 Wire Cloth12mesh Hastelloy C276 Wire Cloth

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

120mesh Hastelloy B Wire Cloth

Specification:

1. Wire Dia: 0.08mm
2. Mesh Count: 120mesh/inch
3. Aperture: 0.132mm
4. Open Area: 39%

5. Material: hastelloy B wire

6. Weight: 0.43kgs/m2

7. Weave type: plain weave

8. Packing: waterproof paper with plastic cloth,then into plywooden box.

Hastelloy Wire has  resistant to hydrochloric acid at all concentrations and temperatures including the boiling points, and also hydrogen chloride gas.

9.products pctures:120mesh Hastelloy B Wire Cloth120mesh Hastelloy B Wire Cloth120mesh Hastelloy B Wire Cloth10. Roll size :

1.02m wide x 30.5m length

1.22m wide x 30.5m length

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

200mesh Hastelloy C276 Wire Cloth

Hastelloy C Grade Wire Cloth (UNS:N10276)

1. Mesh Count: 200mesh/inch

2. Wire Diameter: 0.05mm
3. Width of Opening: 0.077mm
4. Open Area:36%
5. Weave: plain weave

6. Weight: 0.2825kgs/m2

7. Packing: waterproof paper with plastic cloth,then wooden case.

Alloy C-276 is an improved version of alloy C in that it has vastly improved fabricability and resists the formation of grain-boundary carbide precipitates during welding.

Hastelloy C276 Chemical Composition %

C Mn Fe V Ni Si S W P Co Mo Cr
Max Max Min/Max Max Max Max Max Min/Max Max Max Min/Max Min/Max
0.02 1.00 4.00-7.00 0.35 Rem 0.08 0.03 3.00-4.50 0.03 2.50 15.0 – 17.0 14.5 – 16.5

200mesh Hastelloy C276 Wire Cloth

http://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

Hastelloy C22 Wire Cloth

Hastelloy C Grade Wire Cloth ( UNS N06022 )
Mesh/Inch: 6mesh to 200mesh
Wire Dia:0.05mm to 1.20mm
Characteristics of Hastelloy C22 Wire Mesh
l Resistant to pitting, crevice corrosion and stress corrosion cracking

l Outstanding resistance to both reducing and oxidizing media

l Excellent resistance to oxidizing aqueous media

l Exceptional resistance to a wide variety of chemical process environments including strong oxidizers such as ferric acids, acetic anhydride, and seawater and brine solutions

l Resists the formation of grain-boundary precipitates in the weld heat-affected zone

l weld ability.

C Cr Co Fe Mn Mo Ni P
.010 max 20-22.5 2.5 max 2.0-6.0 .50 max 12.5-14.5 Balance .02 max
Si S W V
.08 max .02 max 2.5-3.5 .35 max

Mechanical Property Requirements

Ultimate Tensile

Yield Strength (0.2% OS)

Elong. in 2 in. (50.8mm) or 4D min., %

R/A

Hardness

Min

100 KSi

45 KSi

45

Max

Min

690 MPa

310 MPa

Max

Hastelloy C22 Wire Clothhttp://www.generalmesh.com www.generalmesh.com/blog/

MP:86-137-2282-3064| Skype:jennis01 | Wechat: 13722823064

Tel: +86-318-855784 | Fax: +86-318-7757320

Whatsapp: +8613722823064 |Viber : +8613722823064

E-mail: sales@geneneralmesh.com

180mesh Hastelloy C276 Wire Cloth

Hastelloy C Grade Wire Cloth (UNS:N10276)

1. Mesh Count: 180mesh/inch

2. Wire Diameter: 0.05mm
3. Width of Opening: 0.091mm
4. Open Area:42%
5. Weave: plain weave

6. Weight: 0.25kgs/m2

7. Packing: waterproof paper with plastic cloth,then wooden case.

Alloy C-276 is an improved version of alloy C in that it has vastly improved fabricability and resists the formation of grain-boundary carbide precipitates during welding.

Hastelloy C276 Chemical Composition %

C Mn Fe V Ni Si S W P Co Mo Cr
Max Max Min/Max Max Max Max Max Min/Max Max Max Min/Max Min/Max
0.02 1.00 4.00-7.00 0.35 Rem 0.08 0.03 3.00-4.50 0.03 2.50 15.0 – 17.0 14.5 – 16.5

180mesh Hastelloy C276 Wire Cloth
